all
tolerances are +/- .005" unless otherwise noted
Ticket Specifications:
- No black ink or hole punch can appear in shaded zones
- Black mark should have a minimum PCS of 90% in the infrared range
- Background area in line with black mark should have a maximum PCS of 20% in the infrared range
- Formula for black mark location: b = 5.0" - (ticket length x n), where
• n = 0 for 5.0" < Ticket Length
• n = 1 for 2.5" < Ticket Length ≤ 5.0"
• n = 2 for 1.25" < Ticket Length ≤ 2.5"
- Width = 2.00", 2.12", 2.50", 3.00", 3.25" (all dimensions are +.000", -.030")
NOTE: For 5.50" long ticket, b = 5.0"
This is the adjustable wide opto configuration
|
