General
Print Method: direct thermal
Print Speed: 5” per sec. maximum
Resolution: 203dpi (8 dots/mm); 300dpi (premium upgrade)
Size: 3.0” H x 4.0” W x 3.5” L
Weight: 1.6 pounds (excluding power supply)

Media Transport
Media Type: roll or fanfold
Ticket Thickness: .002” to .007”
Ticket Width: 1” to 3.25”
Minimum Ticket Length: 2.75”
Positioning: optical detector senses center black mark at 1.06” from ticket edge.
Ticket Separation: cutter
Presenter: (optional) holds ticket in place until grabbed by user.
Roll: inner diameter - 1.0” minimum; outer diameter - 7.0” maximum

Interfaces
Standard: Serial and USB
Optional: Ethernet, Bluetooth & Wi-Fi

Protocols
Standard: FGL
Drivers: Windows, Mac and Linux

* Print speed may be affected at extreme tempuratures

Power Requirements
100-240 VAC, 50/60 Hz, 65W max
Amp max 24 V DC, 2.5 Amp max

Environmental
*Operating Temperature: -20 to 60ºC
Relative Humidity: 10% to 90%
Storage Temperature: -40 to 70ºC above specs without condensation

Bar Codes
Most 1D and 2D codes including PDF417 DataMatrix, QR, Aztec

Full speed printing of picket fence and ladder bar codes

Fonts
Resident fonts: 16 bitmapped fonts (including Cyrillic and German characters) and Asian character sets (optional)

Downloadable fonts: HP Soft font / TrueTypes fonts
Downloadable RAM: up to 27MB
Downloadable Flash: up to 12MB (optional)

Graphics
FGL format, PCX format (1bit b/w),
BMP format (1bit b/w)

Web Interface (ethernet only)
Real-time status monitor
Email notification

Projected Life
Cutter: 1 million cuts
Print Head: 100 km of paper
or 100 million dot activations
Bonus: Free print head replacements when exclusively using Boca paper

Warranty
Printer: 1 year, parts and labor
Print head: 90 days

Patents: BOCA has a patented head protection system that prevents premature head failure

Approvals
UL / FCC / CE / CCC
